Shenzhen Faycent Technology Co.,Ltd
SMA Female to U.FL IPX IPEX RF Coax Adapter RG178 Pigtail Jumper Cable For PCI WiFi Card Wireless Router Antenna
SMA Female to U.FL IPX IPEX RF Coax Adapter RG178 Pigtail Jumper Cable For PCI WiFi Card Wireless Router Antenna
Couldn't load pickup availability
QTY: 10-200/201-1K/1001-5K/5001-9999/10K+
Price: 0.6/0.55/0.5/0.45/Inquire better price
Model Numer:SMASFN8-178B
Cable Type: RG178 Coaxial Cable
Frequency Range:DC/6GHz
VSWR.: ≤1.3
Out Impedance: 50 ohm
Return Loss: -11 dB Max
Working Voltage: 170V/50 Hz
Cable Length: 15cm(default)/20/30/40cm/customized
Cable Color: Brown
Cable OD: 1.8mm
Connector: SMA Female to U.FL/IPEX
Conductor Material: 100% Bare Copper
Jacket: FEP+Fabric
Operation Temperature: - 40℃ ~ + 85℃
Storage Temperature:- 40℃ ~ + 85℃
Certificates: ROHS
Insulation Resistance: 1000M ohm
Cable Loss: 1.34 dB / m @ 1GHz
Contact Resistance:
Center Contact: 10M ohm outer
Contact: 5M ohm
Admitted Power:2W
Durability: ≥500 cycles
Waterproof Rate:Waterproof Rate
Price
Price
MOQ:2PCS
Price:Large Quantity, Competitive Prices.
Service
Service
Customization Available Based on Your Designs/Samples
Fast Shipping Guaranteed
Quality Assurance
Premium After-Sales Service
