RP-SMA Female to U.FL IPX IPEX RF Coax Adapter RG178 Pigtail Jumper Cable For PCI WiFi Card Wireless Router Antenna

QTY:  10-200/201-1K/1001-5K/5001-9999/10K+

Price:  0.6/0.55/0.5/0.45/Inquire better price

Model Numer:RPSMASFN8-178B

Cable Type: RG178 Coaxial Cable

Frequency Range:DC/6GHz

VSWR.: ≤1.3

Out Impedance: 50 ohm

Return Loss: -11 dB Max

Working Voltage: 170V/50 Hz

Cable Length: 10-20-30-40cm or customized

Cable Color: Brown

Cable OD: 1.8mm

Connector: RP-SMA Female to U.FL/IPEX

Conductor Material: 100% Bare Copper

Jacket: FEP+Fabric

Operation Temperature: - 40℃ ~ + 85℃

Storage Temperature:- 40℃ ~ + 85℃

Certificates: ROHS

Insulation Resistance: 1000M ohm

Cable Loss: 1.34 dB / m @ 1GHz

Contact Resistance:

Center Contact: 10M ohm outer

Contact: 5M ohm

Admitted Power:2W

Durability: ≥500 cycles

Waterproof Rate:Waterproof Rate。
